1、Product introduction

The KDL vertical multistage pump is a product developed and designed by Kenflo. Its superior hydraulic performance and structural design enable users to effectively reduce operating costs across a wide range of applications.

2、Product features

1. This pump is a segmentally constructed, vertical, multistage centrifugal pump with closed impellers. It features a compact design, light weight, small footprint, low noise and vibration, and high reliability. Its external appearance is protected by a national patent (ZL023728434).

2. Available in nine frame sizes, each with 2 to up to 113 impeller stages. A single-stage configuration can also be supplied upon request. For each pump size, different impeller diameter combinations can be fitted to meet varying performance requirements while minimizing power losses.

3. Axial thrust is primarily balanced by the unique impeller hydraulic design, with any residual thrust taken up by a pair of angular contact ball bearings.

4. For pumps with more than two stages, the suction and discharge nozzles can be oriented at 0°, 90°, 180°, or 270° relative to each other. The standard configuration is 180° opposed.

5. The coupling is located on the discharge side of the pump.

3、Technical parameters

Head: 7.5-395m

Flow rate: 1.8-280m³/h

Pump diameter: Discharge 25~150mm, suction 40~200mm

Medium temperature: up to 105 ℃

4、Application field

Designed for handling clean water or liquids with trace amounts of impurities but no solid particles. Applications include pressurization units in water supply utilities, circulation and cooling systems, fire pump stations, refineries, irrigation systems, high-pressure water stations, and building water boosting. When supplied in stainless steel construction, the pump can also handle clean corrosive liquids.
